Machine Size |
|
Overall dimension (L*W*H) | 3865mm*1050mm*2270mm |
Axle base(Track length on ground) | 1230mm |
Track gauge | 820mm |
Min.Ground clearance | 210mm |
Swing radius at tail | 1125mm |
Track System |
|
Maximum Travel speed | 3.5km/h |
Width of track shoe(Rubber & steel track) | 230mm |
Number of track shoe per side(Steel track only) | 38 pcs |
Number of upper roller/ bottom roller（per side） | 0/4 |
Performance Parameter |
|
Standard bucket capacity | 0.06m³ |
Swing speed | 10~12 rpm |
Max. Grade ability | 35° |
Max. Bucket digging force | 14KN |
Max. Arm digging force | 10KN |
Hydraulic system pressure | 18Mpa |
Machine weight | 2500kg |
Engine |
|
Emission Standard | Euro 5/EPA |
Engine Brand / Power | Kubota Engine D1105 14.2kw perkins Engine 14.7kw Laidong 3TE25 18.4Kw |
Number of cylinder | 3 |
Working Range |
|
Max. Digging height | 3365mm |
Max. Dumping height | 2385mm |
Max. Digging depth | 2050mm |
Max. Vertical digging depth | 1725mm |
Max. Digging radius | 3860mm |
Min .swing radius | 1720mm |
Max. Lifting height of blade | 230mm |
Max. Cutting depth of blade | 275mm |
Boom swing angle(Left) | 75° |
Boom swing angle(Right) | 45° |
